DS18 DS-PRO-TWX6 PRO 1.5 Inch VC Aluminum Super Bullet Tweeter 480 Watts 8-Ohm

Get clearer, louder sound with the DS18 DS-PRO-TWX6.

At a glance

• Impedance: 8 ohm

Details

DS18's new 8 ohm super tweeter is sleek and refined after many years of testing and development. These square aluminum housings hold a titanium 1.5 inch voice coil rated for 240w Program power and 480w MAX power with a ferrite motor structure.

With a 112db sensitivity rating, these tweeters do not need a lot of power to get extremely loud. These tweets have a range of 1.7hz to 20khz so you will be sure you wont miss one crack of the high hat!

KEY FEATURES:

• Sturdy 4x4 aluminum throat for easy mounting and aesthetic symmetrical look.
• 112db sensitivity with a 240w program and 280w peak power rating.
• Mounting depth of 2.75 inches so they will clear most door panel locations with minimal fabrication work.
• Silver bullet resonator helps clear and loud frequencies to carry through the air.
• Nominal Diameter 4 inchx4 inch / 102x102mm
• Nominal Impedance 8 ohms
• Peak Power 480 watts
• Program Power 240 watts
• AES Power 120 watts
• Sensitivity (1w/1m) 112 db
• Frequency Response 1.7Hz-20KHz
• Recommended Hi Pass Crossover 2.5hz

MOTOR:

• Voice Coil Diameter 1.5 inch / 38mm
• Voice Coil Former Material KSV
• Winding Material SN
• Diaphragm Material Titanium
• Body Material Aluminum
• Magnet Material Ferrite
• Magnet Weight 15 oz

MEASUREMENTS:

• Overall Diameter 4 inchx4 inch / 102x102mm
• Front Mount Baffle Cutout 3.5 inch / 90mm
• Overall Depth 2.7 inch/ 69mm
• Mounting Depth 2.5 inch / 65mm
• Motor Diameter 3.5 inch / 90mm

SPECIFICATIONS:

• Installation Guide
