DS18 PRO 10" Water Resistant Hybrid Mid-Range Loudspeaker with Built-in Driver 350 Watts Rms 4-Ohm

The DS18 PRO 10" Water delivers crisp, detailed sound with 350W RMS of power handling.

At a glance

• Power: 350W RMS
• Impedance: 4 ohm

Details

10” Water Resistant Hybrid Loudspeaker With 1.5” Compression Driver Horn

The PRO-HY10.4B is a high-powered, water-resistant hybrid loudspeaker that combines a 10" midrange speaker with a high wattage driver to provide a full range of frequencies at an impressively loud volume.
The PRO-HY10.4B features a 1.5" compression driver horn, made with a titanium diaphragm and neodymium magnet, for clear and powerful high-frequency sound.
With a maximum power handling of 700 watts and a sensitivity of 100 dB, this speaker is perfect for those who want to place a high wattage, high volume loudspeaker with a powerful driver into their motorcycles to save on space and increase the quality of their sound.
The water-resistant cone helps protect the speaker from the elements, making it ideal for outdoor use. The PRO-HY10.4B also has a nominal impedance of 4 ohms, a frequency response range of 40Hz-20KHz, and a recommended hi-pass crossover of 70Hz for improved audio performance and longevity, making it a great choice for a range of audio applications.
The PRO-HY10.4B is an excellent choice for anyone seeking a powerful and versatile speaker for their sound system.

Features:

• 10" Hybrid Coaxial Mid-Range w/Driver
• RMS Power: 350 Watts(700 Watts Peak)
• Impedance: 4 Ohm
• Ferrite & Neodymium Magnets
• Water Resistant IPX5
• 100dB ~ w/Grill

  Specifications:

  SKU
  PRO-HY10.4B
  Nominal Diameter
  10" / 254mm
  Nominal Impedance
  4 Ohm
  RMS Power Handling
  350W
  MAX Power Handling
  700W
  Sensitivity (1w/1m)
  100dB
  Frequency Response
  40Hz - 20KHz
  Recommended HI Pass Crossover
  70Hz
  Number of ways
  2 ways
  Pair or Single
  Single
  Grill Included
  Yes


  Woofer Specifications:

  Voice Coil Diameter
  2" / 50.8mm
  Voice Coil Former Material
  Glass Fiber
  Winding Material
  CCAW
  Cone Material
  Water Resistant Paper (IPx5)
  Surround Material
  Cloth
  Basket Material
  Aluminum
  Basket Color/Finish
  Matte Black
  Magnet Material
  Ferrite
  Magnet Weight
  49 Oz
  Displacement Volume
  2.86L / 0.1ft3


  Thiele & Small Parameters:

  Equivalent Volume Vas
  21.8L / 0.76ft3
  Excursion (one way) Xmax
  10mm
  Free Air Resonance Fs
  95Hz
  Mechanical Factor Qms
  12.59
  Electrical Factor Qes
  0.995
  Total Factor Qts
  0.922
  Mechanical Mass Mms
  26.78g
  Mechanical Compliance Cms
  0.125 mm/N
  BL Factor BL
  6.851
  Voice Coil Inductance Le
  0.313mH
  Cone Area Sd
  352.99 Cm2
  DC Resistance Re
  3.4 ohms
  Mechanical Mass w/o air Mmd
  25g


  Driver Specifications:

  Voice Coil Diameter
  1.5" / 38.6mm
  Voice Coil Former Material
  Kapton
  Winding Material
  CCAW
  Diaphragm Material
  Titanium
  Magnet Material
  Neodymium
  Horn Diameter
  4.25" / 108mm


  Speaker Measurement:

  Overall Diameter
  10.3" / 261.5mm
  Overall Depth
  5.7" / 144.4mm
  Front Mount Baffle Cutout
  9" / 231mm
  Mounting Depth
  5.31" / 135mm
  Motor Diameter
  5.7" / 145mm
