Orion CEA900.1D 900W RMS Class D Monoblock Amplifier – 3600W Max

Looking for more volume without distortion? The Orion CEA900.1D mono amplifier puts out 900W RMS (3,600W peak).

At a glance

• Power: 900W RMS (3,600W peak)
• Channels: Mono
• Class D

Details

The Orion CEA900.1D Cobalt Elite Series is a compact Class D monoblock amplifier delivering up to 900W RMS of clean, controlled bass. Designed for tight, efficient low-end performance, it features a variable low-pass crossover and adjustable bass boost for easy tuning. Built-in protection circuitry guards against thermal, short, and low-voltage issues, while the compact design allows easy installation in tight spaces. Perfect for upgrading factory systems or building a reliable daily bass setup with strong, consistent sound.

Features:

• High-efficiency Class D design delivers strong output with reduced heat and power loss
• Built-in electronic crossover with 12dB/octave low-pass filter for precise tuning
• Adjustable bass boost for enhanced low-frequency control
• Compact chassis for easy installation in tight or hidden spaces
• All-MOSFET power supply and output stage for clean, stable performance
• Remote gain control included for real-time bass adjustment
• 1-ohm stable for flexible subwoofer configurations
• Heavy-duty high-current power and speaker terminals
• Soft turn-on/turn-off with turn-on delay for system protection
• 4-way protection: thermal, DC offset, short circuit, and voltage protection
• Intelligent LED indicator for power and fault monitoring

Specifications:

RMS WATTS @ 1 Ohms: 900W

RMS WATTS @ 2 Ohms: 650W

RMS WATTS @ 4 Ohms: 400W

POWER TERMINAL MANAGEMENT

-Positive Terminals: 1 x 4 AWG.

-Negative Terminals: 1 x 4 AWG.

-Remote Turn-ON Signal: 10 AWG.

-Speaker Output Terminals: 10 AWG.

Frequency Response: 15Hz - 250Hz

Subsonic: 15 - 40Hz

Low Pass Crossover Continuously variable: 50 Hz - 250 Hz

Supply Voltage: 10 - 16V

Input Impedance: 22kOhm

Signal to Noise Ratio: 92dB

Phase Shift: 0/180 Degrees

Bass Boost: 0 - 12dB Variable

Variable Input Level Control: 0.2V - 6.0V

Recommended Fuse Rating: 100A

Dimensions (L x W x H): 8.66" x 5.71" x 2.13"

UPC: 818550014183
