DS18 GEN-X 4-Channel Class D Amplifier – 4×300W RMS 4-Ohm Full-Range Car Audio Power
DS18 GEN-X 4-Channel Class D Amplifier – 4×300W RMS 4-Ohm Full-Range Car Audio Power
Couldn't load pickup availability
The DS18 GEN-X is a 4-channel Class D amp built to drive your speakers or subs with clean, steady power.
At a glance
- Channels: 4
- Class D
Details
Take your system to the next level with the DS18 GEN-X 4-Channel Class D Amplifier – 4×300W RMS 4 Ohm Full-Range Car Audio Power. Engineered for consistent performance and efficiency, the DS18 G3600.4D delivers powerful, clean output in a compact design that fits seamlessly into modern car audio builds. This high-performance DS18 3600 amp 4-channel setup provides strong and reliable power across all four channels, making it ideal for running mids, highs, or even a full-range system. With advanced Class D technology, it ensures maximum efficiency while minimizing heat, allowing longer playtime without sacrificing sound quality.
Built as part of the trusted Gen-X lineup, this DS18 3600 watt amp is designed for both everyday listeners and serious audio enthusiasts who demand clarity, punch, and durability. Whether you're upgrading your setup or building from scratch, the DS18 G3600.4 offers the right balance of power and precision.
Its compact footprint makes installation simple, while maintaining the performance needed for high-output systems. If you're searching for a dependable DS18 3600x4 amplifier that combines efficiency with strong audio performance, this model is a solid choice for achieving crisp mids and detailed highs.
Features:
- 4 Channel Full Range
- Class D
- 2 ~ 4 Ohm Stable
- 4 x 300 Watts @ 4 Ohm
- Power/Protection/Clip Indicator
- Built in Crossover
Specifications:
| SKU | G3600.4D |
| UPC | 810005189972 |
| Class | Digital (D) |
| Amplifier Type | 4 CH Full Range |
| Channels | 4 CH |
| Peak Power | 3600W |
| RMS Power @ 4 Ohm | 4 × 300W |
| RMS Power @ 2 Ohm | 4 × 420W |
| RMS Power @ 4 Ohm Bridged | 2 × 740W |
| Minimum Impedance | 2Ω Stereo / 4Ω Bridged |
| Operating Voltage | 9V – 15V |
Performance & Controls:
| Frequency Response | 20Hz – 20KHz |
| Signal-to-Noise Ratio | >90dB |
| Low Pass Filter | 50Hz – 250Hz |
| High Pass Filter | 50Hz – 250Hz |
| Efficiency @ 4 Ohm | 80% |
| Damping Factor | 78 |
| THD % | 0.01% |
| Input Sensitivity | 0.25V – 6V |
| X-Over Filter Range | 50Hz – 250Hz |
Build & Protection:
| Selectable X-Over | LPF / FLAT / HPF |
| LED Indicators | Power / Protection / Clip |
| Voltage Protection | Yes |
| Clipping Protection | Yes |
| Thermal Protection | Yes |
| Cooling Fan | No |
| Speaker Output Size | 12GA |
| Power Input Size | 4GA |
| Fuse Rating | 120A |
| Remote Level Control | No |
| Body Color / Finish | Matte Black |
