DS18 PRO-HY6MSL 6.5" Mid-Range Shadow Slim Loudspeaker with Built-in Driver 300 Watts 8-Ohms

Replace tired factory sound with the DS18 PRO-HY6MSL.

At a glance

• Impedance: 8 ohm

Details

The DS18 PRO-HY6MSL is a 6.5” slim hybrid loudspeaker with a built-in 1” titanium compression driver horn. Designed for motorcycles, ATVs, and powersports, it delivers 150W RMS / 300W MAX with 93dB sensitivity. Its 2.77” mounting depth, paper cone, neodymium motor, and 8-ohm setup make it perfect for loud, clear sound in tight installs.

Features:

• 6.5" Shallow Hybrid Coaxial Mid-Range w/Driver
• RMS Power: 150 Watts(300 Watts Peak)
• Impedance: 8 Ohm
• Ferrite & Neodymium Magnets
• With Grill
• 93dB

Specifications:

SKU
PRO-HY6MSL
Nominal Diameter
6.5" / 165.1mm
Nominal Impedance
8 Ohm
RMS Power Handling
150W
MAX Power Handling
300W
Sensitivity (1w/1m)
93dB
Frequency Response
120Hz-20Khz
Recommended HI Pass Crossover
140Hz
Number of ways
2 ways
Pair or Single
Single
Grill Included
Yes

UPC: 810097260009

Woofer Specifications:

Voice Coil Diameter
1.5" / 38.6mm
Voice Coil Former Material
KSV
Winding Material
CCAW
Cone Material
Paper
Surround Material
Cloth
Basket Material
Steel
Basket Color/Finish
Glossy Red
Magnet Material
Ferrite
Magnet Weight
17.5 Oz
Displacement Volume

Thiele & Small Parameters:

Equivalent Volume Vas
3.45L / 0.121ft3
Excursion (one way) Xmax
2mm
Free Air Resonance Fs
161Hz
Mechanical Factor Qms
7.653
Electrical Factor Qes
1.496
Total Factor Qts
1.252
Mechanical Mass Mms
6.875g
Mechanical Compliance Cms
129.952 mm/N
BL Factor BL
5.621
Voice Coil Inductance Le
10.78mH
Cone Area Sd
136.848 Cm2
DC Resistance Re
6.5 ohm
Mechanical Mass w/o air Mmd
5.955g

Driver Specifications:

Voice Coil Diameter
1" / 25.4mm
Voice Coil Former Material
Kapton
Winding Material
CCAW
Diaphragm Material
Titanium
Magnet Material
Neodymium
Horn Diameter
3" / 76.2mm

Speaker Measurement:

Overall Diameter
6.92" / 176mm
Overall Depth
3.52" / 89.5mm
Front Mount Baffle Cutout
5.6" / 142mm
Mounting Depth
2.77" / 70.5mm
Motor Diameter
4.33" / 110mm
