DS18 NXL-LXY8 8” Marine Grade Luxury Coaxial Speaker, Flush Magnetic Mount Grill Digital LED & Bullet tweeter - Black – 175W RMS 4-Ohm

Get clearer, louder sound with the DS18 NXL-LXY8, an 8-inch marine speaker rated 175W RMS. Built to handle water, sun and spray for boats, UTVs and towers. Built-in LED lighting adds a custom look.

At a glance

• Power: 175W RMS
• Impedance: 4 ohm

Details

The NXL-LXY8/BK 8″ marine coaxial speaker delivers powerful, clear full-range sound with rugged, all-weather durability and a sleek black finish. Featuring an 8″ woofer and 1″ floating bullet tweeter, it produces high-output audio from 40Hz–20kHz, cutting through wind and engine noise in marine and powersports applications.

Built to handle the elements, it includes an IP65-rated, UV-treated cone and rubber surround, a flush-mount magnetic grille for a clean install, and digital LED backlighting. Compatible with DS18 LC-DRM (sold separately) for full LED color control.

Features:

• 8” 2-Way Marine-Grade Coaxial Speaker
• IP65 Water & UV Resistant Construction
• Floating Bullet Tweeter with Neodymium Magnet
• Digital LED Ring (LC-DRM Compatible)
• Flush-Mount Magnetic Grille for Clean Install

Specifications:

Nominal Diameter
8" / 203mm
Nominal Impedance
4 ohms
RMS Power Handling
175W
MAX Power Handling
350W
Sensitivity (1w/1m)
96 dB
Frequency Response
40Hz-20KHz
Recommended HI Pass Crossover
50Hz
Sold in Pair or Single
Pair

UPC: 810199440941

Body / Features

Grill Type
PC+Stainless Steel
Marine Grade Type
IP65
RGB LED
Yes, Digital LED integrated (behind cone)
Digital LED Chip Type
1815S
Basket Material
Injection Molded Composite ASA with UV Protection Coating
Color / Finish
Black

Woofer Specifications

Voice Coil Diameter
1.5" / 38.6mm
Voice Coil Former Material
Glass Fiber
Winding Material
CCAW
Cone Material
PPI
Surround Material
Rubber
Basket Material
PC
Magnet Material
Ferrite+Neodymium
Magnet Weight
24oz + 1.1 oz

Tweeter Specifications

Voice Coil Diameter
1" / 25.5mm
Voice Coil Former Material
Kapton
Winding Material
CCAW
Diaphragm Material
Aluminium
Magnet Material
Neodymium (N35H)
Magnet Weight
0.4oz

Thiele & Small Parameters

Equivalent Volume
16.92L / 0.59ft3
Excursion (one way)
3mm
Free Air Resonance
58Hz
Mechanical Factor
7.599
Electrical Factor
0.834
Total Factor
0.752
Moving Mass
25.604g
Compliance
0.2875mm/N
Bl Factor
6.016
Voice Coil Inductance
1.4mH
Diaphragm Area
203.58cm2
DC Resistance
3.2 Ohms
Efficiency Bandwidth Product
69.5

Speaker Measurement

Overall Diameter
10.24" / 260mm
Overall Depth
4.5" / 114mm
Front Mount Baffle Cutout
8.62" / 219mm
Mounting Depth
4" / 103mm
Motor Diameter
4.33" / 110mm
