Deaf Bonce Avatar Volcano 12 D2 – 2500W RMS – 12" subwoofer
Deaf Bonce Avatar Volcano 12 D2 – 2500W RMS – 12" subwoofer
Couldn't load pickup availability
Hit harder with the Deaf Bonce Avatar Volcano 12 D2, a 12-inch subwoofer handling 2,500W RMS.
At a glance
- Power: 2,500W RMS
- Size: 12"
Details
Extreme Bass Power in a 12-Inch Package
The Avatar Volcano 12 D2 12" car subwoofer is built for serious SPL and high-output daily systems. It handles 2,500W RMS and 5,000W maximum power, and its 3-inch dual voice coil, massive ferrite motor and 25mm Xmax deliver deep, hard-hitting bass with the durability to keep up under demanding conditions.
Sold individually (1 subwoofer). Also available in a Dual 1-Ohm (D1) version for different amplifier setups.
Technical Specifications
| Spec | Details |
|---|---|
| Model | Avatar Volcano 12 D2 |
| Size | 12" |
| Voice coil configuration | Dual 2 ohm (D2) |
| Voice coil diameter | 3" |
| Voice coil wire | Copper-clad aluminum (CCA) |
| RMS power | 2,500W |
| Max power | 5,000W |
| Frequency response | 20 – 80 Hz |
| Sensitivity | 81.9 dB (D2) |
| Cone | Semi-pressed paper |
| Surround | Foam |
| Magnet | Ferrite |
| Basket | Die-cast aluminum |
| Xmax | 25 mm (0.98") |
| Mounting depth | 8.98" (228 mm) |
| Cutout diameter | 11.14" (283 mm) |
| Gross weight | 51.8 lbs (23.5 kg) |
| Sold as | Single subwoofer |
| SKU | DEF-Volcano12D2 |
| UPC | 4650185712289 |
Why Choose the Avatar Volcano 12 D2?
- 2,500W RMS / 5,000W max handling: power for high-output builds and competition-style systems
- Dual 2-ohm (D2) voice coil: flexible wiring options for a wide range of high-power amplifiers, including multi-sub setups
- 3" high-temperature voice coil: built to handle sustained high power
- 25mm (0.98") Xmax: long, controlled excursion for deep low-end output
- Semi-pressed paper cone: stiff and light for accurate, powerful bass
- High-roll foam surround: supports the cone's excursion
- Massive ferrite motor: strong magnetic drive for high output
- Die-cast aluminum basket: strength and heat dissipation for hard use
- Frequency response 20–80 Hz: tuned for deep bass
Perfect For
- SPL and competition builds
- High-output daily systems for bass lovers
- Single or multi-sub setups with high-power monoblock amplifiers
- Sealed or ported enclosures built to the manufacturer's recommendations
Before You Buy
This is a dual 2-ohm subwoofer. Depending on how the coils are wired (in parallel or series), the final impedance will be 1 ohm or 4 ohms for a single sub. Make sure your amplifier is stable at the impedance you choose and delivers enough clean power. Use proper gauge wiring, a solid ground and a well-built enclosure for best results.
D1 or D2? Choose based on your amplifier's stable load and how many subs you plan to run. Compare with the Avatar Volcano 12 D1 (link to your D1 page).
FAQ
How much power can the Avatar Volcano 12 D2 handle?
2,500W RMS and 5,000W maximum.
What does D2 mean?
Dual 2-ohm: the subwoofer has two 2-ohm voice coils. Wired in parallel it presents 1 ohm, and wired in series it presents 4 ohms.
What is the difference between D1 and D2?
The D1 version has dual 1-ohm coils, giving final impedance options of 0.5 ohm (parallel) or 2 ohms (series). The D2 gives 1 ohm or 4 ohms. Pick the version that best matches your amplifier's stable load and your number of subs.
What size cutout do I need?
11.14" (283 mm) diameter, with a mounting depth of 8.98" (228 mm).
Is this sold as a pair?
No. It is sold individually, as a single subwoofer.
What amplifier should I use?
A high-power monoblock amplifier that is stable at your chosen final impedance and delivers close to the 2,500W RMS rating.
